Features
Name of parameters
50 60 70 80
Flow rate of water (foam agent solution), l/s 50 60 70 80
Nominal pressure, MPa 0,8
Operating pressure range, MPa 0,4-1,0
Stream range (outermost) at nominal pressure, m, not less than::
- straight water stream 68 70 72 74
- dispersed (at a stream discharge angle of 30°) 38 40 42 44
- straight foam 58 60 62 63
Oscillation angles, ° 30±5,70±5, 110±5
Fire monitor displacement speed at oscillation, °/sec 2-6
Working area of monitor rotation, degrees:
- vertical up +90 to -45
- horizontal 360
Weight, kg, not more than -
Useful information
Certificates All certificates

Products: Water-foam fire monitors, universal, with manual and remote control, stationary, portable, trailer-mounted (including construction versions: low - "n", ball-socket - "b", explosion-proof - "Ex") of LS, LSD types, are manufactured in accordance with the Technical specifications TU 4854-003-16820082-2008 with amendment 7.

The products comply with the requirements of the Technical regulations TR EAEU 043/2017 "On the requirements for fire safety and fire extinguishing equipment".

Certificate validity period: from 06.07.2021 till 06.06.2026.
