Features
Name of parameters
20 30 40
Nominal pressure, MPa 0,8
Operating pressure range, MPa 0,4-1,0
Flow rate of water (foam agent solution), l/s 25 30 40
Stream range (outermost) at nominal pressure, m, not less than::
- straight water stream 55 62 65
- dispersed (at a stream discharge angle of 30°) 34 38 42
- straight foam 47 53 55
Angle range of a dispersed water stream, degrees 0-90
Working area of monitor rotation, degrees:
- vertical up +90 to -45
- horizontal 345
Weight, kg, not more than -
Useful information
Certificates All certificates

Products: Water-foam fire monitors, universal, with manual and remote control, stationary, portable, trailer-mounted (including construction versions: low - "n", ball-socket - "b", explosion-proof - "Ex") of LS, LSD types, are manufactured in accordance with the Technical specifications TU 4854-003-16820082-2008 with amendment 7.

The products comply with the requirements of the Technical regulations TR EAEU 043/2017 "On the requirements for fire safety and fire extinguishing equipment".

Certificate validity period: from 06.07.2021 till 06.06.2026.
