LS-S40(20,30)U
Features
| Name of parameters |
100 | 150 | |
|---|---|---|---|
| Nominal pressure, MPa | 0,8 | ||
| Operating pressure range, MPa | - | ||
| Flow rate of water (foam agent solution), l/s | 100 | 150 | |
| Stream range (outermost) at nominal pressure, m, not less than:: | |||
| - straight water stream | 100 | 115 | |
| - dispersed (at a stream discharge angle of 30°) | 61 | 65 | |
| - straight foam | 85 | 95 | |
| Angle range of a dispersed water stream, degrees | 0-90 | ||
| Working area of monitor rotation, degrees: | |||
| - vertical | up +75 to -15 | ||
| - horizontal | 360 | ||
| Weight, kg, not more than | - | ||
Useful information
Certificates
All certificates
Products: Water-foam fire monitors, universal, with manual and remote control, stationary, portable, trailer-mounted (including construction versions: low - "n", ball-socket - "b", explosion-proof - "Ex") of LS, LSD types, are manufactured in accordance with the Technical specifications TU 4854-003-16820082-2008 with amendment 7.
The products comply with the requirements of the Technical regulations TR EAEU 043/2017 "On the requirements for fire safety and fire extinguishing equipment".
Certificate validity period: from 06.07.2021 till 06.06.2026.
