RFSS in a general industrial version is an integrated system with two or more firefighting robots (robotic fire monitors) in a general industrial version, with flow rates from 15 up to 125 l/s, with a program control system and fire detection system. RFSS provides automatic fire extinguishing of industrial and public buildings, high-floored structures and outdoor facilities.
RFSS in a general industrial version is used for protection of industrial and public buildings, high-floored structures and outdoor facilities: hangars for aircrafts and helicopters, production facilities, machinery halls of nuclear power plants and thermal power plants, storage facilities, including rack storage facilities, timber storages, multifunctional buildings, buildings for sports and entertainment events, monuments of wooden architecture.
RFSS is designed in accordance with the requirements of the Codes of practice SP 485.1311500.2020, SP 486.1311500.2020, Russian State standard GOST R 12.3.047 (depending on the protected facility category), Technical specifications TU 4854-005-16820082-2005, other valid regulatory documents and Industry-specific fire safety standards VNPB 39-20. Special technical specifications are not required.
water, water mist, water with wetting agent, mechanical air foam, compressed air foam, gas-filled foam
no more than 60 s
2-128
1
- automatic,
- remote,
- manual,
- start lockout
- extinguishing of load-bearing structures and/or process facilities;
- вetection and extinguishing of the fire source
- positional extinguishing of the predetermined zones;
- contour extinguishing of the predetermined objects;
- positional extinguishing of fire sources detected with the FR fire targeting detectors.
400/230V 50Hz from the automatic transfer switch
from the "Alarm" signal to the start of fire extinguishing, no more than 20 s
not less than normalized in accordance with the current regulatory documents, incl. the requirements of the Code of practice SP 485.1311500.2020, the Company’s Code STO, Special technical specifications STU for the protected facility
Certificate of Conformity № EAEU RU S-RU.ChS13.V00639/22 dated 22.08.2022.
Products: robotic fire suppression systems in general industrial and explosion-proof versions, are manufactured in accordance with the Technical specifications TU 4854-005-16820082-2005 with amendment No. 5 ”Robotic fire suppression systems. Technical specifications”. Serial production
The products comply with the requirements of the Technical regulations TR EAEU 043/2017 "On the requirements for fire safety and fire extinguishing equipment".
Certificate validity period: from 22.08.2022 till 21.08.2027
