Description
Description

Fire monitor water/foam, universal, with manual control, with flow rate of 20 l/s, with automatic nozzle, of tube construction.

The fire monitor is applied for formation of extinguishing solution streams with adjustable spray angle from a straight stream to a dispersed at 90°.

The fire monitor is used in fire hazardous zones for fire suppression, cooling of buildings and technological structures, precipitation of poisoned or radioactive gases, fumes and dusts.

Features:

  • Automatic nozzles enable to form the straight and dispersed streams of fire extinguishing agent with an option of spray angle adjustment. They automatically maintain pressure of fire extinguishing agent providing for the maximum stream range for the given operational range of flow rates.

Fire monitors are produced in accordance with the requirements of Technical Specifications ТU 4854-003-16820082-2008 and TR EAEU 043/2017.

More
Features
Name of parameters
20
Nominal pressure, MPa 0,8
Operating pressure range, MPa -
Flow rate of water (foam agent solution), l/s 20
Working flow rate range, L/s 10-30
Stream range (outermost) at nominal pressure, m, not less than::
- straight water stream 65
- dispersed (at a stream discharge angle of 30°) 34
- straight foam 47
Angle range of a dispersed water stream, degrees 0-90
Working area of monitor rotation, degrees:
- horizontal ±20
- vertical up +20 to +60
- horizontal 360
- vertical up +90 to -45
- vertical up +75 to -15
- horizontal 360
- vertical up +75 to -15
- horizontal 345
- vertical up +80 to +8
- horizontal 180
Displacement speed, degree/s:
- sprinkling / targeting 3-6 / 8-10
Сlimatic category in accordance with GOST 15150-69 У1, UHL 1.1, ОМ1
Weight, kg, not more than 13
