Description

Firefighting robot (robotic fire monitor) based on fire monitors, water/foam, universal, fixed, with flow rate of 10, 15, 20 l/sec, program/remote-controlled, with IR-UV fire targeting detector.

The firefighting robot is applied for formation of extinguishing solution streams with adjustable spray angle from a straight stream to a dispersed at 90°. The firefighting robot is used for fire suppression, cooling of buildings and technological structures, precipitation of poisoned or radioactive gases, fumes and dusts in fire hazardous zones.

More
FR-LSD-S10(15,20)Ub-IR
Features
Name of parameters
10 15 20
Nominal pressure, MPa 0,6 0,6 0,8
Operating pressure, MPa 0,4-1,0
Flow rate of water (foam agent solution), l/s 10 15 20
:
- straight water 32 33 38
- dispersed (at a stream discharge angle of 30°) 16
- straight foam 25
Foam expansion ratio, not less than 7
Angle range of a dispersed water stream, degrees 0-120
Coordinate system -
Rotation speed, °/ sec 3-12
Working area of monitor rotation, degrees:
- vertical от +5 до -65
- horizontal 420
Detection range of the test fire source TP-5 in accordance with GOST R 50898-96 , m, not less than 25
Сlimatic category in accordance with GOST 15150-69 U1
Ingress protection rating of the enclosure in accordance with GOST14254-96 IP55
Weight, kg, not more than 11
Useful information
Certificates All certificates

Certificate of Conformity № EAEU RU S-RU.ChS13.V00639/22 dated 22.08.2022.

Products: robotic fire suppression systems in general industrial and explosion-proof versions, are manufactured in accordance with the Technical specifications TU 4854-005-16820082-2005 with amendment No. 5 ”Robotic fire suppression systems. Technical specifications”. Serial production

The products comply with the requirements of the Technical regulations TR EAEU 043/2017 "On the requirements for fire safety and fire extinguishing equipment".

Certificate validity period: from 22.08.2022 till 21.08.2027
